My tmux and zsh configuration

Me in my pimped-out shell

Here’s a list of things I have in my tmux and zsh configurations, which might offer some inspiration to others.

• zsh configuration
  • Getting aligned on the correct terminal size
  • Setting window title from path or command
  • Resetting terminal state after commands
  • get current git hash faster
  • Changing the appearance of prompts in scrollback
• tmux configuration
  • User options in tmux
  • Detecting an idle shell
  • Recolouring idle tabs
  • box-drawing characters for visual separation
  • Window status and index
  • Cropping tab title to a maximum length on the proper side
  • Git information in tmux status bar
  • Pseudo-terminal in the status bar
  • Stitching it all together
  • A mouse-clickable session selector
  • Unique, per-session status bar colours
  • Create new windows in current working directory
• A couple of other notes

zsh configuration

Here’s some of my ~/.zshrc:

stty size >/dev/null
local _ESC=$'\E'
local _BEL=$'\a'

function win_title() {
  local title="$(tr -d '[:cntrl:]' <<< "$1")"
  print -nr "${_ESC}]0;${title}${_BEL}"
}

function precmd() {
  win_title "$(print -P '%~')"
  stty sane ; print -nr "${_ESC}[?1000l${_ESC}[?9l${_ESC}[0m${_ESC}[2K"
}

function preexec() {
  local cmdline="$2"
  [[ "$cmdline" == "fg" ]] && cmdline="${jobtexts[%+]}"
  win_title "$cmdline"
  print -nr "${_ESC}[0m${_ESC}[2K"
}

function githead() {
  local gitdir="${1:a}"
  until [[ -e "$gitdir/.git" ]]; do
    local updir="${gitdir%/*}"
    [[ "$updir" == "$gitdir" ]] && return 1
    gitdir="$updir"
  done
  gitdir="$gitdir/.git"
  {
    local gitdir_link
    gitdir_link="$(<"$gitdir")" && gitdir="${gitdir_link#gitdir: }"
    local hash="$(<"$gitdir/HEAD")"
    if [[ "$hash" == ref:* ]]; then
      local ref="${hash#* }"
      local gitdir_relative=$(<"$gitdir/commondir") && gitdir="$gitdir/$gitdir_relative"
      hash="$(<"$gitdir/$ref")" || hash="$(git rev-parse --short HEAD)"
    fi
  } 2> /dev/null
  print -r "${hash:+ ${hash::12}}"
  return 0
}

SCROLLBACK_PROMPT="%K{20}%*%v %2~$ %B%F{white}"
SCROLLBACK_PS2="%K{20}${PS2} %BF{white}"
SCROLLBACK_PS3="%K{20}${PS3} %BF{white}"
SCROLLBACK_PS4="%K{20}${PS4} %BF{white}"
function set-scrollback-prompt() {
    psvar[1]="$(githead .)"
    PROMPT="$SCROLLBACK_PROMPT" \
            PS2="$SCROLLBACK_PS2" \
            PS3="$SCROLLBACK_PS3" \
            PS4="$SCROLLBACK_PS4" \
            zle reset-prompt
    zle .accept-line
}
zle -N accept-line set-scrollback-prompt

Getting aligned on the correct terminal size

Sometimes when I connect from a terminal emulator in a weird state, everytihng gets the wrong idea about the size of the window. Running a command which makes the right query gets everyone on the same page, and stty is a good candidate:

stty size >/dev/null

I used to use resize but that’s part of an X11 package and not always available.

Setting window title from path or command

I set the window title from zsh to reflect either the current working directory or the currently-running command. So the tabs in the status bar can be rendered accordingly.

local _ESC=$'\E'
local _BEL=$'\a'

function win_title() {
  local title="$(tr -d '[:cntrl:]' <<< "$1")"
  print -nr "${_ESC}]0;${title}${_BEL}"
}

Control code handling is a bit messy. I put them in variables to stop them from being interpreted at the wrong time: either being expanded after ${title} is expanded, so that any escapes inside of ${title} are also expanded, or when the function is defined, so that when I list function definitions they send stray escape sequences to the terminal (which I don’t appreciate).

There might (must!) be a better way, but what I have seems stable so far, and only slightly unprintable.

So this call goes in precmd():

  win_title "$(print -P '%~')"

And this call goes in prexec():

  local cmdline="$2"
  [[ "$cmdline" == "fg" ]] && cmdline="${jobtexts[%+]}"
  win_title "$cmdline"

I got tired of all my windows ending up being titled fg, so I included a fixup for that.

Resetting terminal state after commands

This in precmd():

  stty sane ; print -nr "${_ESC}[?1000l${_ESC}[?9l${_ESC}[0m${_ESC}[2K"

It restores the terminal to a comparatively usable state after each command, in case something crashes in an ugly state.

get current git hash faster

Putting the output of another command in a shell prompt can be a bit laggy on slow machines, and git is no exception. Performance can be improved by implementing the same functionality inside zsh itself, despite that implementation being interpreted code:

function githead() {
  local gitdir="${1:a}"
  until [[ -e "$gitdir/.git" ]]; do
    local updir="${gitdir%/*}"
    [[ "$updir" == "$gitdir" ]] && return 1
    gitdir="$updir"
  done
  gitdir="$gitdir/.git"
  {
    local gitdir_link
    gitdir_link="$(<"$gitdir")" && gitdir="${gitdir_link#gitdir: }"
    local hash="$(<"$gitdir/HEAD")"
    if [[ "$hash" == ref:* ]]; then
      local ref="${hash#* }"
      local gitdir_relative=$(<"$gitdir/commondir") && gitdir="$gitdir/$gitdir_relative"
      hash="$(<"$gitdir/$ref")" || hash="$(git rev-parse --short HEAD)"
    fi
  } 2> /dev/null
  print -r "${hash:+ ${hash::12}}"
  return 0
}

Here, we iterate up the tree by cutting off directory names until we find a .git directory (or file). If it’s a file, then the content of that file should point inside the actual git directory (these files are created by git worktree). Get the content of the file HEAD, and if that contains ref: then go look up the actual hash in the refs folder (which is actually in the root of the git directory, not the worktree subdirectory).

If the ref is not there then it’s probably a packed ref, so just give up and hand off to the external command line tool instead, because it’s probably not going to be efficient parsing packed refs in this function.

Changing the appearance of prompts in scrollback

The prompt that makes sense for interactive line editing and current status, or whatever, isn’t always the best context thing to have filling up your scrollback.

So you can ask zsh, just before executing a command, to change the prompt settings and have zsh redraw the prompt, and then go ahead and execute the command.

I take the opportunity to set a non-default background colour so that when I’m perusing scrollback I get a clear boundary between output from different commands.

SCROLLBACK_PROMPT="%K{17}%*%v %B%2~$ %b"
SCROLLBACK_PS2="%K{17}%B${PS2} %b"
SCROLLBACK_PS3="%K{17}%B${PS3} %b"
SCROLLBACK_PS4="%K{17}%B${PS4} %b"
function set-scrollback-prompt() {
    psvar[1]="$(githead .)"
    PROMPT="$SCROLLBACK_PROMPT" \
            PS2="$SCROLLBACK_PS2" \
            PS3="$SCROLLBACK_PS3" \
            PS4="$SCROLLBACK_PS4" \
            zle reset-prompt
    zle .accept-line
}
zle -N accept-line set-scrollback-prompt

What this does is temporarily set up a bunch of alternate prompts while calling zle reset-prompt, which will cause the prompt and text input to be redrawn in the styles given by SCROLLBACK_\*. Then it goes on to call the standard accept-line function.

This can cause the output colour to end up as something other than the default, which can be fixed up in preexec():

  print -nr "${_ESC}[0m${_ESC}[2K"

The %v part of the prompt prints what is saved with psvar[1]="...", which in this case is the current git commit hash (as collected in the previous section). This is helpful so that you have a record of what commit the tree was at when a test was run, so that you can find it again if you want to reproduce that result. Provided you don’t have local edits. The information is collected in preexec() to be up to date, even if the state was changed in another window while this one idled.

tmux configuration

Here’s some of my ~/.config/tmux/tmux.conf:

set -g @status_bg "#330066"
set -g @status_fg "#000000"
set -g @shell_idle "#{==:#{pane_current_command},zsh}"
set -g @tab_width "18"
set -g @tab_bg "#{?#{==:#{window_flags},*},cyan,#{?#{E:@shell_idle},blue,green}}"
set -g @tab_left "#[fg=#{E:@tab_bg},bg=#{@status_bg}]🭮#[fg=#{@status_fg},bg=#{E:@tab_bg}]"
set -g @tab_prefix "#{p1:window_flags}#I┊"
set -g @tab_title "#{=/#{?#{E:@shell_idle},-,}#{@tab_width}/… :pane_title}"
set -g @tab_right "#[fg=#{@status_bg},reverse]🭬"
set -g @git_summary "#(~/.config/scripts/gitsummary.sh #{pane_current_path})"
set -g @git_state "#[bg=red,fg=white]#(~/.config/scripts/gitstate.sh #{pane_current_path})#[default]"
set -g @pts "#[fg=blue,reverse]🭡#[default,bg=blue]#{s|/dev/| |:pane_tty} "

set -g status-left " #S#[fg=#{@status_bg},reverse]🭐 "
set -g status-right "#[fg=#{@status_bg},reverse]🭅#[default]#{E:@git_summary}#{E:@git_state}#{E:@pts}"
set -g status-right-length 50
set -g window-status-style "bg=green,fg=#{@status_fg},fill=#{@status_bg}"
set -g window-status-current-style "bg=cyan,fg=#{@status_fg},fill=#{@status_bg}"
set -g window-status-format "#{E:@tab_left}#{E:@tab_prefix}#{E:@tab_title}#{E:@tab_right}"
set -g window-status-current-format "#{E:window-status-format}"
set -g window-status-separator ""

bind -n MouseDown1StatusLeft choose-tree -s

set-hook -g session-created 'run-shell "tmux set -t #D @status_bg \"##$(echo "#h#S" | sha1sum | cut -c-6)\""'

bind '"' split-window -c "#{pane_current_path}"
bind % split-window -h -c "#{pane_current_path}"
bind c new-window -c "#{pane_current_path}"

Refer to the tmux format strings documentation for details, but what follows is a brief description of each part.

User options in tmux

First, ‘user options’ are a thing, where any option name beginning with @ is available for personal use:

set -g @status_bg "#330066"
set -g @status_fg "#000000"
set -g @tab_width "18"

These are expanded in other places using #{@tab_width}. If the option contains more to expand, it can be referenced with, eg., #{E:@shell_idle}.

Detecting an idle shell

If a pane was running a command but has gone back to the shell (ie., is now idle), that’s occasionally worth knowing:

set -g @shell_idle "#{==:#{pane_current_command},zsh}"

This checks to see if tmux sees the current task as zsh. If it is then that means it’s [probably] just waiting for command input. Otherwise something is [probably] running.

This will expand to 0 or 1, to be used in other conditionals.

Recolouring idle tabs

set -g @tab_bg "#{?#{==:#{window_flags},*},cyan,#{?#{E:@shell_idle},blue,green}}"

This returns a colour to use as the background for each tab in the status bar. Cyan for the tab you’re looking at, green for a busy tab, and blue for an idle tab.

box-drawing characters for visual separation

I’m not generally into console bling, but I found that having all the separators be rectangular character cell edges made things harder to read than if I used different shapes. Even if the results aren’t all that pretty I still find it easier to read.

What I’ve done here is put some triangles on the edges of the tabs matching the background colour of the tab, to turn them from rectangles into hexagons:

set -g @tab_left "#[fg=#{E:@tab_bg},bg=#{@status_bg}]🭮#[fg=#{@status_fg},bg=#{E:@tab_bg}]"
set -g @tab_right "#[fg=#{@status_bg},reverse]🭬"

The left part also establishes the background colour for the main body of the tab.

Window status and index

There’s a window-flags string showing a few things, like ! for an alarm state. Apparently I saw need to pad this to one character to stabilise the tab size, suggesting that at some point it was dynamic in length. This doesn’t seem to be necessary anymore, but there it is. Is it ever longer? I’ve never noticed that.

Then the window index #I, then a separator character. I went with the lightest [box-drawing character][] I could find which reaches the full height of the space.

set -g @tab_prefix "#{p1:window_flags}#I┊"

Cropping tab title to a maximum length on the proper side

I don’t want long window titles to produce oversized tabs, so I truncate them:

set -g @tab_title "#{=/#{?#{E:@shell_idle},-,}#{@tab_width}/… :pane_title}"

When zsh is waiting for more input it sets the window title to the current working directory. I don’t want that to be /home/... for every window, so it’s better to truncate from the left.

When a command is running, that becomes the window title, and the essential information there is probably the first word (the command), so I want to truncate from the right. One hopes truncation doesn’t go so far as to create dozens of tabs named simply vim ....

The difference in tmux format specifiers is expressed as whether or not the crop length has a negative prefix on it, as shown above.

Git information in tmux status bar

I prefer my git status in my tmux status bar. Mostly because the handling of slow commands is better, but also because it’s still relevant not just at the prompt but also while I’m editing files or whatever.

set -g @git_summary "#(~/.config/scripts/gitsummary.sh #{pane_current_path})"

And that script looks like:

#!/bin/sh
set -e
cd "$1"
if git rev-parse 2> /dev/null ; then
    echo -n "$(git rev-parse --abbrev-ref HEAD)"
    git log --format=%cr -n2 --reverse . | head -n1 | sed -ne 's/ \(.*\) \(w\|m\|y\)\(eeks\|onths\|ears\) ago/ 👻\1\2👻/p'
fi

This normally just prints the current branch, but if the current directory hasn’t been updated recently it’ll also give the date of the second-newest commit. If that the code hasn’t been touched in a long time that could mean it Just Works™ but often it means it’s been abandoned and I’m looking in the wrong place.

Then there’s the state that git is in:

set -g @git_state "#[bg=red,fg=white]#(~/.config/scripts/gitstate.sh #{pane_current_path})#[default]"

This is normally zero-width, so we don’t have to deal with a bright red patch on the display. If I see red here then I have to wake up.

I use this to print a string representing what state git is currently in, if it’s in the middle of a merge or rebase or whatever. If it’s not an empty string I should probably not try to do anything else.

The script is:

#!/bin/sh
set -e
gitdir=$(git -C "$1" rev-parse --git-dir)
[ -z "$gitdir" ] && exit
r=""
if [ -f "$gitdir/rebase-merge/interactive" ]; then
    r="REBASE-i"
elif [ -d "$gitdir/rebase-merge" ]; then
    r="REBASE-m $(cat $gitdir/rebase-merge/head-name)"
elif [ -d "$gitdir/rebase-apply" ]; then
    if [ -f "$gitdir/rebase-apply/rebasing" ]; then
        r="|REBASE"
    elif [ -f "$gitdir/rebase-apply/applying" ]; then
        r="|AM"
    else
        r="|AM/REBASE"
    fi
fi
echo "$r"

Pseudo-terminal in the status bar

I also print the pts on the status bar for historical reasons. Mostly in case something gets hung up in an awkward way and I need to know which commands were running in that pane.

set -g @pts "#[fg=blue,reverse]🭡#[default,bg=blue]#{s|/dev/| |:pane_tty} "

Stitching it all together

Those user settings are then stitched together into the actual configuration settings:

set -g status-left " #S#[fg=#{@status_bg},reverse]🭐 "
set -g status-right "#[fg=#{@status_bg},reverse]🭅#[default]#{E:@git_summary}#{E:@git_state}#{E:@pts}"
set -g status-right-length 50
set -g window-status-style "bg=green,fg=#{@status_fg},fill=#{@status_bg}"
set -g window-status-current-style "bg=cyan,fg=#{@status_fg},fill=#{@status_bg}"
set -g window-status-format "#{E:@tab_left}#{E:@tab_prefix}#{E:@tab_title}#{E:@tab_right}"
set -g window-status-current-format "#{E:window-status-format}"
set -g window-status-separator ""

I think in previous versions of tmux I needed to pass -F to set those style options, but by not doing that you can update the values dynamically, which is fun.

A mouse-clickable session selector

bind -n MouseDown1StatusLeft choose-tree -s

This makes it so that I can click that session name in status-left, and get a list of sessions to choose from:

Unique, per-session status bar colours

To take the hash of the host and session names, and cut that down to six hex digits to make a random colour on a per-session basis:

set-hook -g session-created 'run-shell "tmux set -t #D @status_bg \"##$(echo "#h#S" | sha1sum | cut -c-6)\""'

Create new windows in current working directory

It generally works better for me to have new shells start out in the working directory of the shell I’m looking at:

bind '"' split-window -c "#{pane_current_path}"
bind % split-window -h -c "#{pane_current_path}"
bind c new-window -c "#{pane_current_path}"

A couple of other notes

While messing about with the configuration file, you can reload it with:

tmux source-file ~/.config/tmux/tmux.conf

In place of tools like xsel or pbcopy/pbpaste, the tmux-equivalent tools for piping into and out of the clipboard are:

... | tmux loadb -
tmux saveb - | ...

Other references:

• tmux format strings
• box-drawing characters
